Pelat dan Lembaran Aluminium Tahan Korosi Temper T66 dengan Ketebalan Premium 0,2-200mm
Product Details
| Kisaran Ketebalan: | 0.2-200mm | Rentang Lebar: | 100-2000mm |
|---|---|---|---|
| Opsi panjang: | 2000mm,2440mm,6000mm | Tipe Paduan: | EN AW-6082 |
| Konten silikon: | 0,20 – 0,60% | Kandungan magnesium: | 0,60 -1,20% |
| Konten mangan: | 0,40 – 1,00% | Kandungan Tembaga: | 0,15 – 0,40% |
| Konten besi: | 0,10 – 0,30% | kandungan kromium: | 0,25% Maks |
| Konten seng: | 0,15% Maks | kandungan Titanium: | 0,20% Maks |
| Melunakkan: | T66 | Minimal UTS: | 245 KKL |
| Kekuatan Hasil: | 200 MPa | ||
| Menyoroti |
Plat Aluminium Tebal 0,2-200mm,Lembar aluminium tahan korosi |
||
Product Description
- Rasio kekuatan-ke-berat yang superior
- Ketahanan korosi yang sangat baik
- Konduktivitas termal dan listrik yang tinggi
- Mudah dibuat dan dibentuk
- Tersedia dalam berbagai finishing
| Artikel | Standar | Bahan paduan | Jangkauan Ukuran |
|---|---|---|---|
| Lembar aluminium | GB/T3190-2008, GB/T3880-2006, ASTM B209, JIS H4000-2006, dll. | 1050, 1060, 2A14, 3003, 3103, 4032, 5454, 5754, 5056, 5082, 5086, 6061, 6060, 6082, 7075, 7475 | Ketebalan: 0,2-200mm, Lebar: 100-2000mm, Panjang: 2000mm, 2440mm, 6000mm, atau sesuai kebutuhan |
| Perbaikan permukaan | Sertifikasi uji pabrik yang disertakan dengan pengiriman, Pemeriksaan Pihak Ketiga dapat diterima | Cerah, dipoles, garis rambut, sikat, ledakan pasir, berkarakter, tergores, mengukir, dll. | N/A |
| Ketentuan Perdagangan | Ex-Work, FOB, CNF, CFR, dll. | TT, L/C, Western Union, dll. | Pengiriman cepat untuk barang yang ada; berdasarkan jumlah pesanan untuk yang lain |
| Jenis Kontainer | Dimensi (L x L x H) | Kapasitas (CBM) |
|---|---|---|
| 20ft GP | 5898mm x 2352mm x 2393mm | 24-26 CBM |
| 40ft GP | 12032mm x 2352mm x 2393mm | 54 CBM |
| 40ft HC | 12032mm x 2352mm x 2698mm | 68 CBM |
| Paduan | % Si | %Mg | % Fe | %Al |
|---|---|---|---|---|
| EN AW-1050 A | 0.25 Max | 0.05 Max | 0.40 Max | 99.5 menit |
| EN AW-1070 A | 0.20 Max | 0.03 Max | 0.25 Max | 99.7 menit |
| EN AW-1100 | 0.95 Max (Si+Fe) | - | - | 99.0 Min |
| EN AW-3003 | 0.60 Max | - | 0.70 Max | Sisanya |
| EN AW-6061 | 0.40 ¢ 0.80 | 0.80 ¢ 1.20 | 0.70 Max | Sisanya |
| EN AW-7075 | - | - | - | Sisanya |
| Paduan | Temperature | UTS (Mpa) Min | Kekuatan hasil (Mpa) Min | Elongasi (%) A 50mm (Min) |
|---|---|---|---|---|
| EN AW-1050 A | O | 60 | 20 | 23 |
| EN AW-1050 A | F | 60 | 20 | 23 |
| EN AW-1100 | O | 75 | - | 25 |
| EN AW-6061 | O | - | - | 14 |
| EN AW-6061 | T6 | 260 | 240 | 6 |
| EN AW-7075 | T6 | 520 | 480 | 5 |
